Features

Featuring high performance in a new innovative, versatile compact design that is great for VR and AI.

• Brainpower that matches yours: The latest Intel® Xeon® processor powers your most demanding applications. Now featuring a new generation of single-socket architecture with up to 18 cores, you can extract maximum performance for your biggest ideas.
• Accelerate every project: Run your software as fast as possible and get real-time results thanks to this memory expandable machine with up to 256GB of faster 2666 MHz RDIMM memory.
• Drown out distraction: Focus on your tasks with the workstation that’s quieter than ever. A new multichannel thermal design delivers advanced cooling and acoustics for enhanced cooling and quiet operation when your system is under heavy workloads.
• Adapts to your innovations: Your Precision 5000 Tower is ready for complex projects, including virtual reality workflows, with the next generation AMD Radeon Pro™ and highest-performing NVIDIA Quadro® graphics. Your workstation supports up to 600W of graphics power and future graphics options up to 300W per card (950W PSU required).

Specification

• Processor Options: Intel® Xeon® Processor W Family CPUs (Skylake-W) with up to 10 cores per processor and Intel Advanced Vector Extensions, Intel Trusted Execution Technology, Intel AES New instructions, Optimized Intel Turbo Boost and optional Intel vPro™ technology.
• Operating System Options: Windows 10 Pro for Workstations (up to 4 Cores)
  Windows 10 Pro for Workstations (4 Cores Plus)
  Windows 10 Pro for Workstations Downgrade to Windows 7 (up to 4 Cores)
  Windows 10 Pro for Workstations Downgrade to Windows 7 (4 Cores Plus)
  Red Hat® Enterprise Linux® 7.3
  Ubuntu Linux 16.04 Suse Linux (SLES 12 SP2) supported
• Chipset: Intel® C422 (Kaby Lake-W)
• Memory options:  Four channel memory up to 256GB 2666MHz DDR4 ECC memory. 8 DIMM slots
  Note: Memory speed is dependent on specific Intel Xeon Processor W Family processor installed.
• Graphics Options: Support for 2 PCI Express® x16 Gen 3 graphics card - up to 600W with maximum of up to 2 x 300W double width graphics cards.
• High end 3D cards:
  Radeon™ Pro WX 9100
  Radeon™ Pro SSG (future)
  NVIDIA Quadro GP100
  NVIDIA Quadro P6000
  NVIDIA Quadro P5000
• Mid-range 3D cards:
  Radeon™ Pro WX 7100
  Radeon™ Pro WX 5100
  Radeon™ Pro WX 4100
  NVIDIA Quadro P4000
  NVIDIA Quadro P2000
• Entry 3D cards:
  Radeon™ Pro WX 3100
  Radeon™ Pro WX 2100
  NVIDIA Quadro P1000
  NVIDIA Quadro P600
  NVIDIA Quadro P400
• Professional 2D cards:
  NVIDIA NVS 310
  NVIDIA NVS 315
