Features

• Powered by 4th and 5th Gen Intel® Xeon® Scalable Processors that support up to 64 cores1 (128 cores per server), 350W TDP.
• Increased memory bandwidth to 5600 MT/s2, performance and lower power requirements with up to 8 TB DDR5 memory capacity with 32 DIMM slots.
• Advanced data transfer rates from the PCIe Gen5 serial expansion bus, support up to 10 standard PCIe Gen5 slots and 2 OCP 3.0 slots3.
• Includes HPE Integrated Lights-Out 6 (iLO 6) server management software that enables you to securely configure, monitor, and update your HPE ProLiant Gen11 servers seamlessly from anywhere.
• Supports hot-pluggable, high-availability, RAID1 protected M.2 NVMe boot option.
• Supports new EDSFF E3.S NVMe form factor to enable higher-density servers and storage systems, optimization of PCIe lanes from CPUs, and ultra-high SSD performance

Specification

• Processor: 5th Gen Intel® Xeon® Scalable Processors and 4th Gen Intel® Xeon® Scalable Processors
• Memory type: HPE DDR5 Smart Memory
• DIMM capacity: 32 DIMM slots
• Drive supported: 4 to 12 LFF SAS/SATA or 8 to 24 SFF SAS/SATA/x1 NVMe HDD/SSD, or 8 SFF x4 NVMe SSD, or 12 EDSFF x4 NVMe SSD, depending on model. Upgrade option kits are available.
• Security: EFI Secure Boot and Secure Start support, Intel® Software Guard Extensions (SGX) support, Immutable Silicon Root of Trust, TPM (Trusted Platform Module) 2.0 support, Front bezel key-lock feature, Padlock slot and Kensington Lock slot support.
• Infrastructure management: HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download); HPE iLO Advanced, and HPE OneView Advanced (require licenses) Compute Ops Management Software.
• Power supply type: 2 Flexible Slot power supplies maximum, depending on model.
• Expansion slots: 2 to 10 PCIe Gen5 (2 OCP 3.0). Refer to the QuickSpecs for more detail.
• Network controller: Choice of optional OCP plus standup
• Storage controller: Choice of optional OCP plus standup.
