Features

The Dell EMC Unity File System is a 64-bit based file system architecture that provides increased maximums to keep pace with the modern data center.

• Unifies block, file, and VMware VVols support
• Provides health scores with CloudIQ for an unlimited amount of Dell EMC Unity arrays
• Delivers all-flash storage from 4 TB to 4.0 PB max raw capacity
• Maximizes the value of flash with inline data reduction and 15.38 TB flash drives
• Protects investment with the Future-Proof Program
• Cost Savings: Mixed workload consolidation onto affordable allflash arrays that can to scale to 16PB effective capacity

Specification

• Unified all-flash platforms with the versatility to consolidate all of an organization’s storage
• Cloud based management with CloudIQ and cloud tiering for SAN and NAS.

Maximum Cable Lengths

• Shortwave optical OM3: 100 meters (16 Gb) 150 meters (8 Gb), 380 meters (4 Gb), and 500 meters (2 Gb)
• Shortwave optical OM4: 125 meters (16 Gb) 190 meters (8 Gb), 400 meters (4 Gb), and 500 meters (2 Gb)

Operating environment

• Recommended Range Operation: 18°C to 27°C (64.4°F to 80.6°F) at 5.5°C (41.9°F) dew point to 60% relative humidity and 15°C (59°F) dew point
• Continuous Allowable Range Operation: 10°C to 35°C (50°F to 95°F) at 20% to 80% relative humidity with 21°C (69.8°F) maximum dew point (maximum wet bulb temperature). De-rate maximum allowable dry bulb temperature at 1°C per 300m above 950m (1°F per 547 ft above 3117 ft).
