Features

• Scale your IT on your own terms,The R340 delivers the flexibility to increase compute, storage, and memory capacity.
• Simplify your IT infrastructure, Reduce the time and effort to manage IT environments by automating everyday tasks.
• Boost your business productivity,The R340 offers features to support your demanding and growing business needs.
• Increase compute performance and the ability to run multiple applications at the same time, by choosing either a 4- or a 6-core Intel Xeon E-2100 processor
• Scale storage and memory depending on your compute requirements
• Deploy multiple servers with iDRAC Group Manager, a built-in “one to many console”
• Harness data growth with up to eight internal 2.5" hot plug HDDs or four 3.5" hot plug HDDs

Specification

• Processor: 1 processor from the following:
  Intel® Xeon® E-2100 product family
  Intel Pentium®
  Intel Core i3®
  Intel Celeron®
• Memory: 4 x DDR4 DIMM slots, Supports UDIMM, up to 2666MT/s, 64GB Max. Supports registered ECC
• Drive bays:
  Up to 8 x 2.5 hot-plug SATA, SAS (optional) or SSD
  Up to 4 x 3.5 hot-plug SATA, SAS (optional) or SSD
• I/O & Ports:
• Networking Options:
  2 x 1GbE LOM Network Interface Controller (NIC) ports
• Front ports:
  1x USB 2.0, 1 x IDRAC micro USB 2.0 management port
  Rear ports: 2 x USB 3.0, VGA, serial connector
• 2 x PCIe Gen 3.0 slots:
  One x8 slot low-profile, half-length with x4 slot width
  One x16 slot low-profile/full-height, half-length with x8 bandwith
• Storage controllers :
  Internal controllers: PERC H730P, H330, HBA330 (non-RAID)
  Software RAID: PERC S140
  External HBAs: 12Gbps SAS HBA (non-RAID)
  Boot Optimized Storage Subsystem: 2x M.2 240GB (RAID 1 or No RAID), 1x M.2 240GB (No RAID only)
